Hydraulic Lifting Table

The Hydraulic Lifting Table is a lifting device with good lifting stability, large carrying capacity and wide application range, and is Suitable for indoor and outdoor loading and unloading.

Send Inquiry

Product Introduction

The Hydraulic Lifting Table is a lifting device with good lifting stability, large carrying capacity and wide application range, and is Suitable for indoor and outdoor loading and unloading.

2M 6M 8M Lifting Height Hydraulic Double Scissor Lift Table

Technical Parameters:

Series	Model	Load (KG)	Self Height (MM)	Max Platform Height (MM)	Platform Size (MM)	Lifting time (S)	Net weight (KG)
Single Scissor	HW1001	1000	205	990	1300×820	20~25	160
	HW1002	1000	205	990	1600×1000	20~25	186
	HW1003	1000	240	1300	1700×850	30~35	200
	HW1004	1000	240	1300	1700×1000	30~35	210
	HW1005	1000	240	1300	2000×850	30~35	212
	HW1006	1000	240	1300	2000×1000	30~35	223
	HW1007	1000	240	1300	1700×1500	30~35	365
	HW1008	1000	240	1300	2000×1700	30~35	430
	HW2001	2000	230	1000	1300×850	20~25	235
	HW2002	2000	230	1000	1600×1000	20~25	268
	HW2003	2000	250	1300	1700×850	25~35	289
	HW2004	2000	250	1300	1700×1000	25~35	300
	HW2005	2000	250	1300	2000×850	25~35	300
	HW2006	2000	250	1300	2000×1000	25~35	315
	HW2007	2000	250	1400	1700×1500	25~35	415
	HW2008	2000	250	1400	2000×1800	25~35	500
	HW4001	4000	240	1050	1700×1200	30~40	375
	HW4002	4000	240	1050	2000×1200	30~40	405
	HW4003	4000	300	1400	2000×1000	35~40	470
	HW4004	4000	300	1400	2000×1200	35~40	490
	HW4005	4000	300	1400	2200×1000	35~40	480
	HW4006	4000	300	1400	2200×1200	35~40	505
	HW4007	4000	350	1300	1700×1500	35~40	570
	HW4008	4000	350	1300	2200×1800	35~40	655
Double Scissors	HD1000	1000	305	1780	1300X820	35-45	210
	HD2000	2000	360	1780	1300X850	35-45	295
	HD4000	4000	400	2050	1700X1200	55-65	520
Three Scissors	HT1000	1000	470	3000	1700x1000	35-45	450
Three Scissors	HT2000	2000	560	3000	1700x1000	50-60	750
Four Scissors	HF400	400	600	4140	1700x1000	30-40	800
	HF800	800	706	4210	1700x1000	70-80	858
	HF2000	2000	850	4200	2500x1500	80-90	980

Product Advantages:

1. 3 Kinds of Control Mode Can choose!Control box:wired remote control, wireless remote control.

2. Support platform size. Function customization, more in line with the needs of customers.

3. Upgraded material, strong and durable, more stable operation!

Product Details:

1. The basic frame is made of rectangular square steel-field platform frame with anti-skid plate. The plate or stainless steel plate can effectively reduces the deformation of the table.

2. Support arm frame materials are made of high strength 16Mn steel rectangular tube or standard channel steel composite plate.

3. All sliding bearings are self-lubricated bearings with new composite materials, simple maintenance and long service life.

4. The hydraulic system of main oil cylinder is adopted with anti-crack which automatically locks the oil cylinder when the tubing is broken.

5. The hydraulic system has a power failure emergency manual descending device.
